fixed 7W Audio equipments SQP type cement resistor

Metal plate fixed cement resistor:
Packing:Bulk packing
Product type:SQP type , SQM type, SQZ type, SQH type, MPR type
Tolerance:±5%, ±10%
Resistance Value Range:0.1 OHM-150K OHM
Testing Standard:JISC 5202
Availability:
Quantity:
  • SQP
  • HKR

APPLICABLE SCOPE


1.1 This specification is for use in CEMENT TYPE RESISTOR

1.2 Characteristics and specifications are according to those of:


MIL-STD-105

MIL-STD-202

JIS C 5202

GB 5731-85

IEC 115-2-1-1982

QC 400101


1.3 RoHS and REACH compliant product


TYPE


It is composed of description , rated wattage , nominal resistance , tolerance and packaging.


2.1 Explanation of part numbers:


2.2 Explanation :


Part Number Description


SQP 1000 10R J BP Cement Type Resistor, 10W, 10Ω, +/-5% tolerance , bulk pack.


SQM
