Product Description:
5w Vertical Cement Resistor For Broadcasting
Series: Dip Resistor
Tolerance: ±5%
Resistance Value range: Full value
Packing: BULK PACKAGE
Power rating: 1W 2W 3W 5W
Dimensions (unit: mm)：
DESCRIPTION 内容 | SQp100 | SQp200 | SQp300 | SQp500 | SQp700 | SQp1000 | SQp1500 | SQp2000 | SQp2500 |
POWER RATINGAT70℃ 额定功率(70℃) | 2W | 3W | 5W | 7W | 15W | 20W | 25W | ||
OPERAT RANGE 使用温度范围 | -40℃ ~＋155℃ | -40℃ | -40℃ ~＋155℃ | -40℃ ~＋155℃ | -40℃ ~＋155℃ | -40℃ ~＋155℃ | -40℃ ~＋155℃ | -40℃ ~＋155℃ | -40℃ ~＋155℃ |
TEMPERATURE COEFFICIENT 温度特性 | ±350PPM | ±350PPM | ±350PPM | ±350PPM | ±350PPM | ±350PPM | ±350PPM | ±350PPM | ±350PPM |
NCE 绝缘电阻 | MIN. 20 MΩ | MIN. 20 MΩ | MIN. 20 MΩ | MIN. 20 MΩ | MIN. 20 MΩ | MIN. 20 MΩ | MIN. 20 MΩ | MIN. 20 MΩ | MIN. 20 MΩ |
HUMIDITY 耐湿负荷寿命 | ±(5%R+0 . 05Ω) | ±(5%R＋0 . 05Ω) | ±(5%R＋0 . 05Ω) | ±(5%R＋0 . 05Ω) | ±(5%R＋0 . 05Ω) | ±(5%R＋0 . 05 ) | ±(5%R＋0 . 05Ω) | ± | ±(5%R＋0 . 05Ω) |
SHORT- T 短时间过负荷 | ±(2.5%R+0.05Ω) | ± | ± |
| ± | ± | ± |
| ± |
SOLDERABILITY 焊锡性 | MIN. 95% COVERED | MIN. 95% COVERED | MIN. 95% COVERED | MIN. 95% COVERED | MIN. 95% COVERED | MIN. 95% COVERED | MIN. 95% COVERED | MIN. 95% COVERED | MIN. 95% COVERED |
LOAD LIFE 负载寿命 | ±(5%R＋0 . 1Ω) | ± | ± | ± | ± | ±(5%R＋0. 1Ω) | ± | ± | ± |
FLAMERETARDANT 不燃性 | NO FLAMING | NO FLAMING | NO FLAMING | NO FLAMING | NO FLAMING | NO FLAMING | NO FLAMING | NO FLAMING | NO FLAMING |
Why choose us?
1.Fast delivery time
With adequate monthly capacity of SMD resistors 15 Billion PCS and through hole resistors 20 Million PCS, we can secure fast delivery time to all the customers.
2. High quality
With more than 35 years in the industry, we well know the relevant standards and manufacture products based on requirements, also we have perfect quality system and tools to monitor the product from raw materials to finished products to secure quality .
3. Professional and reliable team
With a professional and experienced team, we understand every requirement of our customers and always try out best to satisfy them.
4. Quick Response
If you have any enquires or problem, please feel free to contact with us, we will try to answer you within 24 hours.
F.A.Q
Question 1
Question: Does the sample fee can be returned?
Answer: We can provide free samples.
Question 2
Question: How long will it take to receive my order?
Answer: The lead-time depends on your order quantity and destination.
Welcome to contact us freely for more details about our products!
