20w Wirewoundrods Cement Resistor For Communication

Availability:

Quantity:



Inquire Add to Basket

Product Description

Product Description:

Series: Dip Resistor

Tolerance: ±5%

Resistance Value range: Full value

Packing: BULK PACKAGE

Power rating: 1W 2W 3W 5W

Dimensions (unit: mm)：

DESCRIPTION 内容	SQp100	SQp200	SQp300	SQp500	SQp700	SQp1000	SQp1500	SQp2000	SQp2500
POWER RATINGAT70℃ 额定功率(70℃)		2W	3W	5W	7W		15W	20W	25W
OPERATNGTEMP. RANGE 使用温度范围	-40℃ ~＋155℃	-40℃ ＋155℃	-40℃ ~＋155℃	-40℃ ~＋155℃	-40℃ ~＋155℃	-40℃ ~＋155℃	-40℃ ~＋155℃	-40℃ ~＋155℃	-40℃ ~＋155℃
TEMPERATURE COEFFICIENT 温度特性	±350PPM	±350PPM	±350PPM	±350PPM	±350PPM	±350PPM	±350PPM	±350PPM	±350PPM
NSULATONRESISTA NCE 绝缘电阻	MIN. 20 MΩ	MIN. 20 MΩ	MIN. 20 MΩ	MIN. 20 MΩ	MIN. 20 MΩ	MIN. 20 MΩ	MIN. 20 MΩ	MIN. 20 MΩ	MIN. 20 MΩ
HUMIDITY 耐湿负荷寿命	±(5%R+0 . 05Ω)	±(5%R＋0 . 05Ω)	±(5%R＋0 . 05Ω)	±(5%R＋0 . 05Ω)	±(5%R＋0 . 05Ω)	±(5%R＋0 . 05 )	±(5%R＋0 . 05Ω)	±5%R＋0 . 05Ω)	±(5%R＋0 . 05Ω)
SHORT- TEOVERLOAD 短时间过负荷	±(2.5%R+0.05Ω)	±2. 5%R＋0.05Ω	±2.5%R＋0.05Ω)	2.5%R＋0.05Ω	±2.5%R+0.05Ω)	±2.5%R＋0.05 )	±2.5%R＋0.05Ω	2.5%R＋0.05	±2.5%R＋0.05 )
SOLDERABILITY 焊锡性	MIN. 95% COVERED	MIN. 95% COVERED	MIN. 95% COVERED	MIN. 95% COVERED	MIN. 95% COVERED	MIN. 95% COVERED	MIN. 95% COVERED	MIN. 95% COVERED	MIN. 95% COVERED
LOAD LIFE 负载寿命	±(5%R＋0 . 1Ω)	±5%R＋0. 1 )	±5%R＋0 . 1Ω)	±5%R＋0. 1Ω	±5%R＋0 . 1Ω)	±(5%R＋0. 1Ω)	±5%R＋0 . 1Ω)	±5%R＋0. 1 )	±5%R＋0. 1Ω
FLAMERETARDANT 不燃性	NO FLAMING	NO FLAMING	NO FLAMING	NO FLAMING	NO FLAMING	NO FLAMING	NO FLAMING	NO FLAMING	NO FLAMING

Why choose us?

1.Fast delivery time
With adequate monthly capacity of SMD resistors 15 Billion PCS and through hole resistors 20 Million PCS, we can secure fast delivery time to all the customers.

2. High quality
With more than 35 years in the industry, we well know the relevant standards and manufacture products based on requirements, also we have perfect quality system and tools to monitor the product from raw materials to finished products to secure quality .

3. Professional and reliable team
With a professional and experienced team, we understand every requirement of our customers and always try out best to satisfy them.

4. Quick Response
If you have any enquires or problem, please feel free to contact with us, we will try to answer you within 24 hours.

F.A.Q

Question 1

Question: Does the sample fee can be returned?

Answer: We can provide free samples.

Question 2

Question: How long will it take to receive my order?

Answer: The lead-time depends on your order quantity and destination.

Welcome to contact us freely for more details about our products!
